Fireproof ACP
Class A2 Solid-Core Panel
Features a dense, mineral-filled core sealed between dual aluminum skins. This non‑combustible construction meets A2‑S1‑d0 (EN 13501‑1 / GB/T 8624) standards, offering zero flame spread, low smoke output, and no droplet emission. Ideal for high-rise façades and demanding safety projects
Class A2 Corrugated-Core Lightweight Panel
Built with a corrugated or embossed aluminum core, this innovative Class A2 non‑combustible panel dramatically reduces weight (≈ 3.8–4.9 kg/m² vs 5.4–6 kg/m² for solid-core), while maintaining full fire resistance and superb flatness. It offers enhanced thermal insulation through its air‑gap core, is 100% recyclable, and enables striking façade designs with easier handling and installation .
Class B1 Flame-Retardant Panel
Engineered with a flame-resistant core that achieves B1 classification under GB/T standards. It resists ignition and halts flame propagation when the heat source is removed, providing also excellent structural rigidity, aesthetic options (PVDF/PE coatings), and ease of installation—perfect for projects requiring robust fire safety at a mid‑range cost .
All three options deliver the hallmark benefits of aluminum composite panels—superior flatness, durability, impact resistance, and extensive finishing choices (PVDF, FEVE, polyester coatings). Whether prioritizing absolute non‑combustibility, cost‑effective flame retardancy, or ultralight fire‑safe design, our panels meet diverse architectural and safety needs.
| A2 Solid Core | A2 Corrugated | B1 | ||
| Aluminum Alloy | AA1100, AA3003, AA5005 | AA3003, AA5005 | AA1100, AA3003, AA5005 | |
| Aluminum Skin (mm) | 0.21, 0.3, 0.35, 0.4, 0.45, 0.5 | 0.4, 0.45, 0.5, 0.7, 1.0 | 0.21, 0.3, 0.35, 0.4, 0.45, 0.5 | |
| Panel Thickness (mm) | 4, ,5 ,6 | 4, 5 | 3, 4, 5, 6 | |
| Panel Width (mm) | 1220, 1250, 1500 | 1220, 1250, 1500 | 1220, 1250, 1500 | |
| Panel Length (mm) | 2440, 3050, 4050, up to 6000 | 2440, 3050, 4050, up to 6000 | 2440, 3050, 4050, up to 6000 | |
| Surface Treatment | PE / PVDF | PVDF | PE / PVDF / FEVE | |
| Colors | 70 colors | 70 colors | 70 colors | |
| Glossy | 20% - 80% | 20% - 80% | 20% - 40% |
| Item | Thickness | Weight | Flatness | Fire Performance EN13501-1 | |
| Solid Aluminum | 3mm | 7.7 - 8.5 kgs/m2 | Fair | A2 | |
| Solid Core ACP | 4mm | 5.4 - 6.0 kgs/m2 | Excellent | A2 | |
| Corrugated ACP | 4mm | 3.9 - 4.9 kgs/m2 | Excellent | A2 |
